Product Features
◇Nozzle mirror makes a more direct observation of positioning of nozzle and
rubber mould.
◇Upgraded clamp unit allows a wider range of application than previous
generation;
◇Position of clamp cylinder is adjustable according to rubber mould’s center
point of force;
◇First innovative front hanging clamp unit in the industry; Standard clamp and
large clamp are switchable on one wax injection machine;
◇Fast rise and fall structure for clamp unit, operators do not need any tools
when processing rubber mould of various thickness on one wax injectior.
Two fingers are well enough to easily position the nozzle and rubber mould
into perfect match.
◇Temperature, time and pressure are controlled by digital circuit, more
accurate than logic simulation circuit;
________________________________________________________________________________
Specifications
Wax Injector Specifications | |
Power Supply | Single Phase, AC 100-220V±10%，50/60Hz |
Rated Power | 500W |
Temperature Display Range | 40.0～99.9℃ (104～212℉ ) |
Temperature Setting Range | 40.0～90.0℃ (104～194℉ ) |
Temperature Accuracy | ±0.5℃ |
Vacuum Timing Setting Range | 0～99.9(S) |
Wax Injection Timing Setting Range | 0.1～600(S) |
Time Accuracy | 0.1S |
Timing for Heating | 0～99H |
Wax Vat Volume | Roughly 3KG |
Pressure Gage Scope | 0～0.25MPa (0～2.5Kg/cm²) |
Fuse Rated Current | 5A |
Packing Size | L 532 x W 382 x D 565 mm |
Net Weight | 21.5KG |
Clamp Unit Specifications External Pressure Input 0.4～0.7MPa Pressure Regulating Valve Pressure Range 0.25～0.3MPa Pressure Sensor Display Range - 5～240KPa primary Wax Injection Pressure Setting Range 10～220Kpa Secondary Wax Injection Pressure Setting Range 10～220Kpa Secondary Wax Injection Start Time Setting Range 0～99.9(S) Clamp Pressure Setting Range 30～235Kpa Forward Pressure Setting Range 65～235Kpa Clamp hold Time Setting 0～300(S) Max Pieces Counting 0～9999 Data Storage 10,000 Starting Mode Magnetic Field Reaction or Press Button Rubber mould Size (Standard) L 135 x W 105 x D 45 (max) Rubber mould Size (Large) L 135 x W 135 x D 60 (max) Packing Size L 543 x W 278 x D 540 mm Net Weight 12KG
